Professional Trinocular Compound Microscope w/ 3D Stage 40X-2000X

Key Features:

Simul-focal trinocular head boasting three unique features
- simultaneous view clear images through trinocular port and eyepieces
- adjustable simul-focal trinocular port
- industry standard 23mm photo port and C-mount port
3D double-layer mechanical stage with Abbe condenser and iris diaphragm
Sturdy metal framework and coaxial coarse & fine focusing

Description:

This professional trinocular microscope features a unique "simul-focal" optical system with an adjustable trinocular port to enable well-focused clear images on your PC or video screen while simultaneously obtaining sharp, focused images through the eyepieces. Most trinocular microscopes allow you to view either through the trinocular port or the eyepieces only, forcing you to switch between the two. Since these trinocular ports are not "simul-focal" with the rest of the microscope optical system, you have to re-focus the microscope after each switch. This microscope, however, erases this step by providing "simul-focal" viewing. Especially handy for teaching demonstrations, clinical examinations and laboratory applications, the "simul-focal" feature allows your students or colleagues to view clear images simultaneously while you work through the eyepieces. In addition, them microscope's industry standard 23mm photo port can be converted into a C-Mount port by attaching the included C-mount adapter, allowing you to attach most microscope digital cameras and video systems on the market.

It includes a 30-degree inclined 360-degree swiveling, compensation-free trinocular head, a 3-D mechanical stage, and an intensity-variable halogen illumination system. This microscope is a perfect laboratory instrument for clinics, vets, doctors, and professional mycologists. Made by the same OEM supplier that provides optical instruments for Leica, Zeiss, Nikon and Olympus, it arrives brand new in a factory sealed box and retails for more than $1,700.

Features:

"Simul-focal" Optical System Allows Simultaneous Viewing Through the Photo Port and Eyepieces
Adjustable Simul-focal Trinocular Port
Industry Standard 23mm Photo Port and C-mount Port
30-Degree Inclined, 360-Degree Swiveling Compensation Free Trinocular Head
Photo/Video Capability with Adjustable 23mm Photo Mount for "Simul-Focal" Image System
Large 3-D Double Layer Mechanical Stage with Stain Resistant Finish
Low-Position Coaxial Stage Movement Control Knobs
Coaxial Coarse & Fine Focusing with CA Knob Tension Control
Fully Coated Optical System with High Resolution
Eight Magnification Settings: 40X-80X-100X-200X-400X-800X-1000X-2000X
Upward Stage Stopper to Protect Slides and Objectives
Abbe Condenser with Iris Diaphragm & Filters
Rack and Pinion Adjustment for Condenser
Built-in Halogen Illumination System with Variable Intensity
Dual Focusing Control Knobs
Full Optical Glass Elements
Precise Ground Glass Lenses
All Metal Mechanical Components.
Adjustable Interpupillary Distance
Adjustable Diopter on Ocular
Solid Metal Frame Construction with Stain Resistant Enamel Finish
CE and GS Approvals
Excellent Five (5) Year Factory Warranty

Specifications:

Nosepiece: quadruple
Mechanical Tube Length: 6-5/16" (160mm)
Head: 360-degree swiveling compensation free trinocular head inclined at 30-degree
Eyepieces: WF10X and P20X
Achromatic Objectives: 4X, 10X, 40X (spring), 100X (spring, oil)
Stage Dimensions: 5-1/2"x 5-1/2" (140x140mm)
Stage Traveling Range: 2-15/16"x 1-3/4" (75x45mm)
Focusing Range: 1-3/16" (30mm)
Division of Fine Focusing: 0.0000787" (0.002mm)
Abbe Condenser: NA=1.25 with rack and pinion focusing control
Illumination: 6V/20W halogen bulb
Power Supply: 110V (220V version available), CE & GS certified
Accessories: 6V/20W spare halogen bulb, bottle of immersion oil, blue, green & yellow filters
Microscope Dimensions: 12" x 9" x 16"
Weight: 20 lbs

Packing List:

One Trinocular Compensation-Free Head with 23mm Adjustable Photo Port and C-Mount Adapter
One Microscope Body with Frame, Base and Halogen Illumination System
Four High Quality DIN Objectives, 4X, 10X, 40X and 100X
Two Pairs of Widefield Eyepieces, WF10X and WF20X
Three Color Filters
One Dust Cover
One Power Cord
One 6V/20W Spare Halogen Bulb
One Spare Fuse
Immersion Oil
User's Manual
