This smart, WiFi-enabled, plug-and-play temperature controller requires no hardwiring and is perfect for regulating and automating the temperature in your mushroom growroom or greenhouse. The unit's WiFi capability allows the user to monitor temperature from anywhere with an Internet connection. This device can be used to maintain the temperature of your mushroom grow room by cutting on/off a space heater or A/C unit within a specified temperature range. The dual relay design allots a dedicated socket to both heating and cooling functions, allowing the user to hookup both heating (e.g. electric space heater) and cooling (e.g. A/C or fan) units to the device simultaneously. (This controller can also control a single device.) This easy-to-use, safe and reliable dual relay output temperature controller is designed with compressor delay protection for refrigeration, high and low temperature alarms, and a sensor fault alarm, which makes for an extremely safe and reliable device. This is a plug-and-play unit, meaning that all you need to do is plug your heating or cooling device into it and it will work. NO HARDWIRING REQUIRED.
Instruction manual included.
Main features:
- This WiFi smart controller supports both Apple IOS & Android. Download the app to monitor temperature anywhere/anytime with an Internet connection
- Works with any 2.4 GHz WiFi router
- Plug and play design, easy to use;
- Dual relay output, be able to connect with refrigeration and heating equipment at the same time;
- Support reading with Centigrade or Fahrenheit unit;
- Maximum output load: 1000W(110V)/2000W(220V);
- Dual display window, be able to display measured temperature and set temperature at the same time;
- Temperature calibration;
- Compressor delay protection for refrigeration control;
- High and low temperature alarms are available;
- Over-temperature and sensor fault alarm;
- Heating/Cooling differential function could be set separately for refrigeration and heating to protect temperature controller from violent change.
Specifications:
- Temperature Control Mode :On/Off Control, Heating and Cooling
- Temperature Control Range : -50~99 °C / -58~210 °F
- Temperature Resolution: 0.1 °C / 0.1°F ?
- Temperature Accuracy: ±1°C (-50 ~ 70°C) / ±1°F (-50 ~ 160° F)
- Ambient Temperature: -30~ 75 °C / -22~ 167 °F
- Input Power: 100 ~240VAC, 50Hz/60Hz
- Temperature Control Output: Max. 10A, 100V ~240V AC
- Input Power Cable Length: 1.5m (5ft) ?
- Output Power Cable Length: 30cm (1ft) ?
- Buzzer Alarm: High and Low Temperature Alarm
- Sensor Type: NTC sensor (Including)
- Sensor Length: 2m / 6.56ft
- Relay Capacity: Cooling/ Heating (10A, 100-240VAC)
- Storage Temperature: -20~ 60 °C / -4~ 140 °F ?
- Storage Humidity: 20~85% (No Condensate) ?
- Dimension Body: 140x68x33mm (5.5x2.7x1.3inch)
- Warranty: 1Year
Package:
- 1 x Temperature controller with outlet,
- 1 x English Manual
